The Datasensing FFI8/BP-1EAN Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection principle with a long sensing distance of up to 1000 mm, these sensors are equipped with PNP NO+NC output types and an M12 connection. They are engineered to operate efficiently in challenging environments, with a robust stainless steel AISI 316L housing and PA12 plug, ensuring durability and resistance to harsh conditions. The sensors offer a high switching frequency of 500Hz and a rapid response time of 1ms, making them ideal for fast-paced applications. With a nominal sensing distance of 800mm and a thermal drift of Sr at 10%, they maintain accuracy and stability, aided by green and yellow LED indicators for stability and output state. The sensors are protected against short-circuits and reverse polarity, and they can withstand interference from external light sources up to 10,000 lux. Certified with CE, cULus, and ECOLAB approvals, they meet stringent safety and performance standards, including Ex nA IIC T6 and Ex tD A22 IP67 T85°C ratings for hazardous environments. The package includes M18 x 1 nuts for easy installation, and the sensors are designed to operate within a temperature range of -25°C to +80°C, ensuring reliable performance without freezing.
- Nominal sensing distance:
- 800mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 35mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green Stability
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5.000lux (incandescent lamp), 10.000lux (sunlight)
- Housing Material:
- Stainless steel AISI 316L / PA12 plug
- Connections:
- M12 plug
- Active Head Material:
- PA12
- Tightening torque:
- 50Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus ECOLAB Diversy Ex: II 3G Ex nA IIC T5 Gc II 3D Ex tc IIIB T95°C Dc
- EMC compatibility:
- EN 60947-5-2
- Supplied Accessories:
- Nuts M18 x 1
- Dimensions:
- M18x1/L=83mm
- Operating Temperature:
- - 25°C + 80°C (Without freeze)
- Mechanical Protection:
- IP68, IP69K
