Datasensing FFI8/BP-1EV5 Sensors
Datasensing
$149.75
The Datasensing FFI8/BP-1EV5 Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an axial diffuse reflection function, these sensors offer a nominal sensing distance of 800mm, making them ideal for long-distance applications. The sensors are equipped with a PNP NO + NC output type and provide a teach-in sensitivity adjustment for easy setup. Housed in a smooth M12 stainless steel casing, they ensure durability and resistance to harsh environments, with an IP68 and IP69K mechanical protection rating. The sensors operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 35mA and a load current capacity of ?100mA. They are equipped with LED indicators for stability and output state, ensuring clear operational status. With a high switching frequency of 500Hz and a rapid response time of 1ms, these sensors are perfect for dynamic applications. Additionally, they offer robust protection features, including short-circuit and reverse polarity protection. The FFI8/BP-1EV5 Sensors are CE, cULus, and ECOLAB Diversey approved, ensuring compliance with international standards. Suitable for a wide temperature range of -25°C to +80°C, these sensors are built to perform in diverse conditions without freezing.
- Nominal sensing distance:
- 800mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 35mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green Stability
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5.000lux (incandescent lamp), 10.000lux (sunlight)
- Housing Material:
- Stainless steel AISI 316L / PA12 plug
- Connections:
- M12 plug
- Active Head Material:
- PA12
- Diameter/Dimension:
- Ø 17,5mm
- Approvals:
- CE cULus ECOLAB Diversey
- EMC compatibility:
- EN 60947-5-2
- Dimensions:
- 17,5/L=83mm
- Operating Temperature:
- - 25°C + 80°C (Without freeze)
- Mechanical Protection:
- IP68, IP69K
- User Manuals:
- View
