The Datasensing FFRL/BP-1EAN Sensors are advanced photoelectric sensors designed for precise detection of transparent objects. Featuring an M18 axial retroreflective design, these sensors offer a nominal sensing distance of 1.5 meters with a minimum blind zone of 100mm. They are equipped with a PNP NO+NC output type, ensuring reliable performance with a switching frequency of 500Hz and a rapid response time of 1ms. The sensors operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 35mA and a load current of ?100mA.
Constructed with a robust stainless steel AISI 316L housing and PA12 plug, these sensors are built to withstand harsh environments, offering mechanical protection rated at IP68 and IP69K. They are also equipped with LED indicators for stability and output state, and feature short-circuit and reverse polarity protection for enhanced safety. The sensors are compatible with RL113G or RL116 reflectors and are approved by CE, cULus, ECOLAB, and Diversy Ex standards, ensuring compliance with international safety and quality regulations.
Ideal for applications requiring high precision and reliability, the Datasensing FFRL/BP-1EAN Sensors are perfect for use in environments with high levels of external light interference, withstanding up to 5,000 lux from incandescent lamps and 10,000 lux from sunlight. The sensors are supplied with M18 x 1 nuts for easy installation and are designed to operate efficiently in temperatures ranging from -25°C to +80°C.
- Nominal sensing distance:
- 1,5m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Minimum sensing distance (blind zone):
- 100mm
- Function Principle:
- Transparent object
- Notes:
- On RL113G or RL116 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 35mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green Stability
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5.000lux (incandescent lamp), 10.000lux (sunlight)
- Housing Material:
- Stainless steel AISI 316L / PA12 plug
- Connections:
- M12 plug
- Active Head Material:
- PA12
- Tightening torque:
- 50Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus ECOLAB Diversy Ex: II 3G Ex nA IIC T5 Gc II 3D Ex tc IIIB T95°C Dc
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- Nuts M18 x 1
- Dimensions:
- M18x1/L=83mm
- Operating Temperature:
- - 25°C + 80°C (Without freeze)
- Mechanical Protection:
- IP68, IP69K
