Datasensing FLIE/00-0C Sensors
Datasensing
$72.65
Emet. 8m T style M18 plast. cavo 5m anti-interf.
- Nominal sensing distance:
- 8m
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Notes:
- (3m for car washes)
- Emitter/Receiver:
- Emitter
- Operating Voltage:
- 19,2 28,8VDC
- LED indicators:
- Green (RUN)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (850nm)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 570 g la coppia
- Housing Material:
- PBT + PC
- Connections:
- 5m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- -20..60°C (without freeze)
- Storage temperature:
- -30..90°C (without freeze)
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Degree of protection:
- IP67 (front-head IP69K)
- Operating Temperature:
- - 20°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67 (front-head IP69K)
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- Catalog:
- View
