Datasensing FQI7/BP-1E Sensors
Datasensing
$108.40
The Datasensing FQI7/BP-1E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring an axial diffuse reflection principle, these sensors offer a nominal sensing distance of 400mm, with a thermal drift of Sr at ?10% Sr and a repeat accuracy of 5%. The sensitivity can be easily adjusted using a trimmer, making it adaptable to different environments and targets, such as a white Kodak 90% 200 x 200mm target.
Constructed with a robust nickel-plated brass housing and a PC plug, the FQI7/BP-1E ensures durability and longevity, even in harsh conditions. It boasts an IP67 protection degree, providing complete protection against dust and water ingress, as well as electrical damages. The sensor is equipped with a PNP NO+NC output type, offering complementary output functions for versatile application needs.
With a switching frequency of 250Hz and a response time of just 2ms, the FQI7/BP-1E delivers fast and accurate detection. It operates efficiently within a voltage range of 10
30VDC, with a no-load supply current of ?30mA and a load current of ?50mA. The sensor also features short-circuit protection with autoreset, overvoltage, and reverse polarity protection, ensuring reliable performance and safety.
The FQI7/BP-1E is designed to withstand external light interference up to 5000lux from incandescent lamps and 10000lux from sunlight, thanks to its LED infrared emission at 880nm. It is EMC compatible with EN 60947-5-2 standards and can endure shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27.
Supplied with M18 x 1 nuts and a screwdriver, the sensor is easy to install and maintain. Its compact dimensions of M18 x 1 /L =66,3mm and a weight of 60g make it suitable for space-constrained applications. The operating temperature range of -25°C to +70°C ensures reliable performance in various environmental conditions. Approved by CE, the Datasensing FQI7/BP-1E Sensors are a dependable choice for your sensing needs.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 60g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
