Datasensing FQI8/BP-0E Sensors
Datasensing
$108.40
The Datasensing FQI8/BP-0E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring an axial diffuse reflection principle, these sensors offer a nominal sensing distance of 1.2 meters, making them ideal for detecting objects at both short and long ranges. The sensors are equipped with a PNP NO+NC output type, providing versatile connectivity options.
Constructed with a durable plastic housing and an IP67 protection degree, the FQI8/BP-0E sensors are built to withstand harsh environments, offering complete protection against electrical damages, including short-circuit, overvoltage, and reverse polarity protection. The sensors are also CE approved, ensuring compliance with international safety standards.
With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors deliver quick and accurate detection. The sensitivity can be easily adjusted using a trimmer, allowing for customization based on specific application needs. The sensors are equipped with LED indicators for status output, ensuring easy monitoring and maintenance.
Designed to operate efficiently in temperatures ranging from -25°C to +70°C, the FQI8/BP-0E sensors are suitable for a wide range of industrial environments. The package includes M18 x 1 nuts and a screwdriver for easy installation. With their robust design and reliable performance, the Datasensing FQI8/BP-0E Sensors are an excellent choice for enhancing automation and efficiency in your operations.
- Nominal sensing distance:
- 1,2m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 20g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
