Datasensing FQIC/BP-0A Sensors
Datasensing
$78.91
The Datasensing FQIC/BP-0A Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring an axial retroreflective function with a nominal sensing distance of 6 meters, these sensors are equipped with a PNP NO+NC output type, ensuring versatile integration into existing systems. The robust construction includes a nickel brass or plastic housing, providing durability and protection with an IP67 rating, making them suitable for harsh environments.
These sensors offer a wide range of models, including direct diffuse, retro-reflective, polarized, and fixed-focus options, catering to diverse sensing needs. With a high switching frequency of 250Hz and a rapid response time of 2ms, they deliver quick and accurate detection. The sensors are equipped with LED infrared emission at 880nm, ensuring reliable performance even in challenging lighting conditions, with resistance to external light interference up to 5000lux from incandescent lamps and 10000lux from sunlight.
The FQIC/BP-0A Sensors are designed with complete protection against electrical damages, including short-circuit protection with auto-reset, overvoltage, and reverse polarity protection. They operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA and a load current of ?50mA. The sensors are easy to install with a 2-meter PVC cable connection and come with supplied accessories, including M18 x 1 nuts for secure mounting.
Ideal for applications requiring precise and reliable sensing, the Datasensing FQIC/BP-0A Sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring high performance and safety in industrial environments.
- Nominal sensing distance:
- 6m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflex
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (senza withdensa)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
