Datasensing FQRL/BP-0E Sensors
Datasensing
$107.78
The Datasensing FQRL/BP-0E Sensors offer a versatile solution for various sensing applications with their wide range of models, including direct diffuse, retro-reflective, polarized, and fixed-focus options. These sensors are designed to handle both short and long sensing distances, making them suitable for diverse environments. Constructed with durable nickel brass or plastic housing, they ensure longevity and reliability. The sensors feature NO+NC complementary output and boast an IP67 protection degree, providing complete protection against electrical damages.
With a nominal sensing distance of 1.5m and a thermal drift of Sr ?10% Sr, these sensors maintain high accuracy with a repeat accuracy of 5%. The sensitivity can be easily adjusted using a trimmer, and they are optimized for transparent objects, particularly when used with RL113G or RL116 reflectors. The axial optic position and PNP NO+NC output type enhance their functionality.
Operating at a switching frequency of 250Hz and a response time of 2ms, these sensors are efficient and responsive. They operate within a voltage range of 10
30VDC, with a no-load supply current of ? 30mA and a load current of ?50mA. The sensors are equipped with short-circuit protection, overvoltage, and reverse polarity protection, ensuring safe and reliable operation.
The LED indicators provide clear status output, and the sensors are resistant to external light interference up to 5000lux (incandescent lamp) and 10000lux (sunlight). With dimensions of M18 x 1 /L =66,3mm and a weight of 30g, they are compact and easy to install using the M12 plug connection. The sensors are designed to withstand operating temperatures from -25°C to +70°C without freezing, and they come with supplied accessories, including nuts and a screwdriver, for convenient setup.
Approved by CE and compliant with EMC compatibility standards EN 60947-5-2, these sensors are built to endure shocks and vibrations as per IEC standards, making them a reliable choice for industrial applications.
- Nominal sensing distance:
- 1,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,1m
- Function Principle:
- For transparent objects
- Notes:
- On RL113G or RL116 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
