Datasensing FQRL/BP-1E Sensors
Datasensing
$116.85
The Datasensing FQRL/BP-1E Sensors are designed for precision and reliability in detecting transparent objects. Featuring an axial retroreflective design, these sensors offer a nominal sensing distance of 1.5 meters with a minimum blind zone of 0.1 meters. The robust nickel-plated brass housing ensures durability, while the IP67 protection degree guarantees resistance against dust and water. With a PNP NO+NC output type, these sensors provide versatile connectivity options. The sensors are equipped with a trimmer for sensitivity adjustment and have a repeat accuracy of 5%. They operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA. The FQRL/BP-1E Sensors are built to withstand harsh environments, with an operating temperature range of -25°C to +70°C and protection against electrical damages such as short circuits and overvoltage. The sensors are CE approved and EMC compatible, ensuring compliance with industry standards. Supplied with M18 x 1 nuts and a screwdriver, these sensors are easy to install and maintain, making them an ideal choice for various industrial applications.
- Nominal sensing distance:
- 1,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,1m
- Function Principle:
- For transparent objects
- Notes:
- On RL113G or RL116 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
