Datasensing FS1/0N-E Sensors

The Datasensing FS1/0N-E Sensors are compact optical fibre amplifiers designed for precision and reliability in various industrial applications. With dimensions of just 49 x 26 x 15 mm, these units are engineered to fit into tight spaces, featuring a right-angle cable exit or M12 plug cable to minimize overall dimensions. The amplifier offers a trimmer for sensitivity adjustment, allowing for fine-tuning to meet specific requirements. It supports both NPN and PNP outputs with selectable NO/NC functions, providing flexibility in integration. The FS1/0N-E utilizes a red light beam with a visible spot, compatible with a wide range of optical fibres, including both plastic and glass types. It is equipped with comprehensive protection against electrical damage, including short-circuit and reverse polarity protection, ensuring durability and longevity. The unit is designed for easy installation with M4 screws and offers a high switching frequency of 1kHz and a rapid response time of 500µs. Operating within a voltage range of 10 to 30VDC, the amplifier maintains a low no-load supply current of ? 30mA and a load current of ?100mA, with minimal leakage current. It features LED indicators for output state and is resistant to interference from external light sources, making it suitable for challenging environments. The housing is made from durable polyamide, and the device is rated IP67 for mechanical protection, ensuring it can withstand harsh conditions. The FS1/0N-E is CE approved and EMC compatible, meeting rigorous industry standards for performance and safety.
