Datasensing HEE/00-3F Sensors
Datasensing
$93.20
The Datasensing HEE/00-3F Sensors are high-performance photoelectric sensors designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 10kHz, ensuring rapid response times. The robust stainless steel housing provides complete protection against electrical damages and meets the IP67 protection degree, making it suitable for harsh environments. With a nominal sensing distance of 1 meter, these sensors are equipped with a yellow LED status indicator for easy monitoring of power status.
Operating within a supply voltage range of 10 to 30 VDC, the HEE/00-3F Sensors offer short-circuit and reverse polarity protection, ensuring durability and safety. The sensors are designed with an axial optic position and emit LED infrared light at 880nm, withstanding interference from external light sources up to 5,000 lux. The compact design, with dimensions of M8x0.75 and a length of 54mm, allows for easy integration into various systems.
These sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring reliable performance in industrial applications. The operating temperature range of -25°C to +70°C, along with shock and vibration resistance, further enhances their versatility. Supplied with M8 x 0.75 nuts, the Datasensing HEE/00-3F Sensors are the ideal choice for applications requiring precise and dependable sensing solutions.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
