Datasensing HEE/00-4F Sensors
Datasensing
$93.20
The Datasensing HEE/00-4F Sensors are high-performance photoelectric sensors designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency and a nominal sensing distance of 2 meters. The robust stainless steel housing ensures durability, while the IP67 protection degree offers complete protection against electrical damages and environmental factors. With a supply voltage range of 10 to 30 VDC, these sensors are equipped with LED status indicators for easy monitoring. The emitter operates with LED infrared emission at 880nm, providing excellent interference resistance to external light sources up to 5,000 lux. Designed for ease of use, the sensors come with an M8 plug 3-pin connection and are supplied with M8 x 0.75 nuts for secure installation. The compact design, with dimensions of M8x0.75/L=54mm and a weight of just 15g, makes them ideal for various industrial applications. Additionally, the sensors offer short-circuit and reverse polarity protection, ensuring reliable operation in demanding environments. Approved with CE and compliant with EMC compatibility standards, the Datasensing HEE/00-4F Sensors are a dependable choice for your sensing needs.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Notes:
- (EG=2)
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
