Datasensing HER/AN-3A Sensors
Datasensing
$143.05
The Datasensing HER/AN-3A Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 10Khz, ensuring rapid response times of just 50 µs. With a nominal sensing distance of 1 meter, they are ideal for various industrial applications. The sensors operate on a supply voltage range of 10 to 30 VDC and are equipped with an NPN NO output type, providing a maximum load current of 100mA.
Constructed with a robust stainless steel housing and an IP67 protection degree, these sensors are built to withstand harsh environments. They offer complete protection against electrical damages, including short-circuit and reverse polarity protection, and are resistant to impulsive overvoltage. The LED status indicator provides clear operational feedback, while the axial optic position ensures precise detection.
The HER/AN-3A Sensors are designed to handle thermal drift of ?10%Sr and maintain repeat accuracy of ?10%. They are equipped with a 2-meter PVC cable for easy installation and connectivity. With approvals from CE and EMC compatibility with EN 60947-5-2, these sensors meet high safety and performance standards. Ideal for use in environments with temperatures ranging from -25°C to +70°C, they are also resistant to shocks and vibrations as per IEC standards.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN NO
- Output Function:
- NO
- Switching frequency:
- 10Khz
- Response time:
- 50 µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 40g
- Housing Material:
- Stainless Stee AISI 303l / PA12 cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
