Datasensing HER/AN-3F Sensors
Datasensing
$146.64
The Datasensing HER/AN-3F Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 10Khz, ensuring rapid response times of just 50 µs. The robust stainless steel housing provides complete protection against electrical damages and is rated IP67 for superior resistance to dust and water ingress.
With a nominal sensing distance of 1 meter, these sensors are equipped with a yellow LED status indicator for easy monitoring. They operate on a supply voltage range of 10 to 30 VDC and are designed with NPN NO output type, making them suitable for various industrial applications. The sensors offer complete protection with features like short-circuit protection, reverse polarity protection, and impulsive overvoltage protection.
The HER/AN-3F Sensors are engineered to withstand harsh environments, with an operating temperature range of -25°C to +70°C. They are also resistant to external light interference, withstanding up to 3,000 lux from incandescent lamps and 5,000 lux from sunlight. The compact design, with dimensions of M8x0.75/L=49mm and a weight of just 15g, ensures easy integration into existing systems.
Approved by CE and compliant with EMC compatibility standards EN 60947-5-2, these sensors are built to meet rigorous industrial standards. The package includes M8 x 0.75 nuts for secure installation, making the Datasensing HER/AN-3F Sensors a reliable choice for your sensing needs.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN NO
- Output Function:
- NO
- Switching frequency:
- 10Khz
- Response time:
- 50 µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Dimensions:
- M8x0,75/L=49mm
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Dimensions:
- M8x0,75/L=54mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
