Datasensing HER/CP-3F Sensors
Datasensing
$146.64
The Datasensing HER/CP-3F Sensors are advanced photoelectric sensor receivers designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 10Khz, ensuring rapid response times of just 50 µs. The robust stainless steel housing provides complete protection against electrical damages and is rated IP67 for superior resistance to dust and water ingress. With a nominal sensing distance of 1 meter, these sensors are equipped with a yellow LED status indicator for easy monitoring.
Operating within a supply voltage range of 10 to 30 VDC, the HER/CP-3F Sensors offer PNP NC output functionality with a maximum load current of 100mA. They are engineered with essential protective features, including short-circuit and reverse polarity protection, as well as impulsive overvoltage protection. The sensors are designed to withstand external light interference up to 3,000 lux from incandescent lamps and 5,000 lux from sunlight, making them suitable for various industrial environments.
The compact design, with dimensions of M8x0.75 and a length of 49mm, ensures easy integration into existing systems. The sensors are constructed with high-quality materials, including a PMMA active head and AISI 303 stainless steel housing, ensuring durability and longevity. With CE approvals and EMC compatibility per EN 60947-5-2 standards, the Datasensing HER/CP-3F Sensors are a reliable choice for demanding applications. Supplied with M8 x 0.75 nuts, these sensors are ready for immediate installation and operation in temperatures ranging from -25°C to +70°C.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP NC
- Output Function:
- NC
- Switching frequency:
- 10Khz
- Response time:
- 50 µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Dimensions:
- M8x0,75/L=49mm
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Dimensions:
- M8x0,75/L=54mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
