Datasensing IL1/CN-4F Sensors

The Datasensing IL1/CN-4F Sensors are high-performance inductive sensors designed for precision and reliability. With compact dimensions of 10 x 28 x 16 mm, these sensors are perfect for applications where space is limited. They operate on a supply voltage of 10 to 30 Vdc and can handle an output current of up to 300 mA. The sensors feature an NPN NC connection with an M8 plug, ensuring easy integration into various systems. Equipped with a yellow LED status indicator, the IL1/CN-4F sensors provide clear visual feedback on their operational state. They boast an IP67 housing protection, making them resistant to dust and water ingress, and offer complete protection against electrical damages, including short-circuit, reverse polarity, and impulsive overvoltage protection. The sensors have a nominal sensing distance of 6mm and an operating distance of 0 to 4.8mm, with a standard target size of 18x18mm FE360. They exhibit a correction factor of 0.41 for copper, 0.50 for aluminium, 0.55 for brass, and 0.75 for stainless steel. With a thermal drift of Sr less than 10% and repeat accuracy under 5%, these sensors ensure consistent performance. Designed for proximity functions, the IL1/CN-4F sensors have a switching frequency of 3kHz and a no-load supply current of ? 10mA. They can handle a load current of up to 300mA with a leakage current of ? 0.12mA and an output voltage drop of ? 1.5V at 100mA. The sensors are built to withstand mechanical shocks and vibrations as per IEC standards and are CE approved for quality assurance. Constructed with durable PA housing and active head material, these sensors are lightweight at just 7g and can operate in temperatures ranging from -25°C to +70°C. The IL1/CN-4F sensors are ideal for industrial environments requiring robust and reliable sensing solutions.
