Datasensing IL9/CN-3F Sensors
Datasensing
$127.81
The Datasensing IL9/CN-3F Sensors are high-performance inductive sensors designed for precise proximity detection. With a compact 8x8 mm cubic design and a sensing head positioned at the center, these sensors offer a nominal sensing distance of 2mm and an operating range of 0 to 1.62mm. They are equipped with an NPN-NC output type and feature a robust M8 plug connection for easy integration.
Constructed from durable AISI303 stainless steel, the IL9/CN-3F sensors are built to withstand harsh environments, boasting an IP67 protection rating. They are engineered to handle a wide range of temperatures from -25°C to +70°C, ensuring reliable performance in various industrial settings. The sensors are shielded for flush mounting and include advanced protection features such as short-circuit, reverse polarity, and impulsive overvoltage protection.
With a switching frequency of up to 5kHz and a repeat accuracy of less than 5%, these sensors provide fast and accurate detection. The blue LED indicator clearly displays the output state, while the low power consumption ensures efficient operation. The IL9/CN-3F sensors are CE and cULus approved, meeting stringent EMC compatibility standards (IEC 60947-5-2) and are resistant to shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. Ideal for applications requiring precise and reliable sensing, these sensors are a versatile choice for modern automation systems.
- Nominal sensing distance:
- 2mm
- Operanting distance:
- 0 1,62mm
- Standard target:
- 8x8mm FE360
- Correction Factor:
- copper: 0,19 / aluminium: 0,15 / brass: 0,25 / stainless steel: 0,61
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- 8x8x59mm cubic flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NC
- Switching frequency:
- ? 5kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,5V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Blue LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 15g
- Housing Material:
- AISI303 Stainless Steel
- Connections:
- M8 Plug
- Active Head Material:
- PBT
- Material:
- AISI303 Stainless Steel
- Diameter/Dimension:
- 8x8x59mm
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Mechanical Protection:
- IP67
