Datasensing INC1/D0-3V Sensors
Datasensing
$408.65
The Datasensing INC1/D0-3V Sensors are designed for precise inclination measurement with a 360° operative range and a resolution of 0.025° at RS485. This single-axis sensor features both digital and analogue outputs, including RS485 with a 57600 baud rate and selectable voltage and current analogue outputs. Housed in a robust M18 AISI316L stainless steel casing, it offers IP67 protection, making it suitable for harsh environments. The sensor is equipped with a 200mm cable and an M12 pigtail plug for easy connectivity. It operates efficiently within a voltage range of 19.2 to 28.8 Vdc and consumes less than 1W of power. LED indicators provide clear status updates, including run mode, memory programming, RS485 data transit, and alarm activation. The sensor is protected against reverse polarity and impulsive overvoltage, ensuring reliable performance. It is CE approved and comes with two nuts for secure installation. Ideal for applications requiring accurate angular position detection, this sensor operates effectively in temperatures ranging from -25°C to +70°C and can be stored in conditions as low as -30°C.
- Operative range:
- 360°
- Resolution:
- 0,025° (@ RS485)
- Detection Axes:
- 1
- Technology:
- MEMS
- Output type:
- Digital + Analogue (I/V selectable)
- Output Function:
- Angular position
- Digital Output:
- RS485 57600 baud rate - 1 bit stop - no parity
- Voltage Analogue Output:
- 0 5V / 0 10V (selectable)
- Current Analogue Output:
- 4 20mA / 0 20mA / 0 24mA (selectable)
- Operating Voltage:
- 19,2 28,8 Vdc
- LED indicators:
- Green: Run mode Yellow: writing/programming memory Blue: transit of RS485 packet data Red: alarm active
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Power Consumption:
- < 1 W
- Digital Resolution:
- 14 bit @RS485
- Analogue Resolution:
- 12 bit
- Load Resistor (Voltage):
- 1k? 1M?
- Load Resistor (Current):
- 100 500?
- Housing Material:
- Stainless steel AISI316L (body) Grilamid (cable exit)
- Connections:
- pigtail 200mm + M12- 5 poles
- Active Head Material:
- Stainless steel AISI316L
- Storage temperature:
- -30°C + 90°C (without ice)
- Approvals:
- CE
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Mechanical Protection:
- IP67
