Datasensing MSC/00-0A Sensors
Datasensing
$110.00
The Datasensing MSC/00-0A Sensors are designed for precision and reliability in various industrial applications. These photoelectric sensors feature a retroreflective function with a nominal sensing distance of 4.5 meters, ensuring accurate detection even in challenging environments. The sensors are equipped with a 2-meter PVC cable and housed in a robust PBT/PC material, providing durability and protection against electrical damage.
With a wide range of models available, including diffuse, retro-reflective, polarized, through-beam detection, and background suppression, these sensors cater to diverse needs. The through-beam models boast a high sensing range, while the retro-reflective models utilize red visible polarized light for enhanced performance. Additionally, models with right angle optics and fixed distance background suppression are available for specialized applications.
The MSC/00-0A Sensors offer selectable NO/NC output functions and a switching frequency of 80Hz, with a response time of just 6.25ms. They operate on a voltage range of 10 to 30VDC, with a no-load supply current of ?30mA and a load current of ?100mA. The sensors are equipped with red LED indicators for status output and feature short-circuit and overvoltage protection for added safety.
Designed to withstand harsh conditions, these sensors have an operating temperature range of -25°C to +70°C and are protected against shocks and vibrations according to IEC standards. With an IP67 degree of protection, they are suitable for use in demanding environments. The sensors are CE and cURus approved, ensuring compliance with international standards. Supplied with M18 x 1 nuts, the MSC/00-0A Sensors are ready for seamless integration into your system.
- Nominal sensing distance:
- 4,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflex
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
