Datasensing MV2/C0-0A Sensors
Datasensing
$108.75
The Datasensing MV2/C0-0A Sensors are designed for precision and reliability in various industrial applications. These photoelectric sensors feature a diffuse reflection function with a nominal sensing distance of 100mm, making them ideal for short-distance detection tasks. The sensors are equipped with a robust M12 plug cable exit, available in both axial and right-angle shapes, ensuring versatile installation options. With a high degree of protection (IP67), they are fully safeguarded against electrical damage and environmental factors.
The sensors operate efficiently within a wide voltage range of 20 to 253VAC at 50-60Hz, and they are capable of handling load currents from 5 to 300mARMS. They boast a low leakage current of 6A and a minimal output voltage drop of ?3V at full load. The LED indicators provide clear status output, while the sensors' high switching frequency of 25Hz and quick response time of 20ms ensure fast and accurate performance.
Constructed with durable materials such as PBT/PC for the housing and PMMA for the active head, these sensors are built to withstand harsh conditions, including temperatures ranging from -25°C to +70°C. The sensors are also resistant to shocks and vibrations, adhering to IEC standards, and are EMC compatible as per EN 60947-5-2. Supplied with M18 x 1 nuts for secure mounting, the Datasensing MV2/C0-0A Sensors are a reliable choice for demanding industrial environments.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- TRIAC NC
- Output Function:
- NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
