The Datasensing MV4/C0-0A Sensors are designed for precision and reliability in various industrial applications. These photoelectric sensors feature a diffuse reflection function with a nominal sensing distance of 200mm, making them ideal for short-distance detection tasks. The sensors are equipped with a robust PBT/PC housing and a 2m PVC cable, ensuring durability and flexibility in installation. With an IP67 protection rating, they offer complete protection against dust and water ingress, making them suitable for harsh environments.
The MV4/C0-0A model boasts a high output current and low leakage current, ensuring efficient performance. It operates on a wide voltage range of 20 to 253VAC at 50-60Hz, with a no-load supply current of ? 30mARMS. The sensor's output type is TRIAC NC, with a load current capacity of 5 to 300mARMS and an output voltage drop of ?3V at full load. The device is equipped with red LED indicators for status output, providing clear visual feedback.
Engineered for stability, the sensor maintains a repeat accuracy of 5% and a thermal drift of Sr ?10%Sr. It features a switching frequency of 25Hz and a response time of 20ms, ensuring quick and accurate detection. The sensor is resistant to external light interference, withstanding up to 3,000 lux from incandescent lamps and 10,000 lux from sunlight.
The MV4/C0-0A is designed with an axial optic position and an M12 plug cable exit, available in both axial and right-angle shapes. It includes supplied accessories such as M18 x 1 nuts for secure mounting. The sensor is compliant with CE and cURus approvals and meets EMC compatibility standards EN 60947-5-2. It is also tested for shocks and vibrations according to IEC standards, ensuring reliable performance in demanding conditions. With an operating temperature range of -25°C to +70°C, the Datasensing MV4/C0-0A Sensors are a versatile and dependable choice for your sensing needs.
- Nominal sensing distance:
- 200mm
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- TRIAC NC
- Output Function:
- NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
