Datasensing MV6/A0-0E Sensors
Datasensing
$121.63
The Datasensing MV6/A0-0E Sensors are advanced photoelectric sensors designed for reliable performance in various industrial applications. Featuring a diffuse reflection function with a nominal sensing distance of 400mm, these sensors are ideal for medium-distance detection tasks. The robust design includes a plastic connector with an M12 plug, available in both axial and right-angle shapes, ensuring versatile installation options.
Engineered for durability, the MV6/A0-0E sensors boast a high degree of protection against electrical damage, with an IP67 rating for complete resistance to dust and water ingress. The sensors operate efficiently within a wide voltage range of 20 to 253VAC at 50-60Hz, and they are equipped with a TRIAC NO output type, supporting a load current range of 5 to 300mARMS. The low leakage current of 6A and output voltage drop of ?3V at full load ensure minimal energy loss and optimal performance.
With a compact M18x1 housing and a lightweight design of just 30g, these sensors are easy to integrate into existing systems. The active head is made from durable PMMA material, and the housing is constructed from PBT/PC for enhanced longevity. The sensors are capable of withstanding operating temperatures from -25°C to +70°C, making them suitable for a variety of environmental conditions.
Additional features include a red LED indicator for status output, a fast switching frequency of 25Hz, and a quick response time of 20ms. The sensors are also designed to resist interference from external light sources, with a tolerance of up to 3,000 lux from incandescent lamps and 10,000 lux from sunlight. Certified with CE and cURus approvals, and compliant with EMC compatibility standards EN 60947-5-2, the Datasensing MV6/A0-0E Sensors are a reliable choice for precision sensing needs.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- TRIAC NO
- Output Function:
- NO
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
