Datasensing MV6/C0-0A Sensors
Datasensing
$113.73
The Datasensing MV6/C0-0A Sensors are designed for precision and reliability in various industrial applications. This photoelectric sensor features a diffuse reflection function with a nominal sensing distance of 400mm, making it ideal for medium-distance detection tasks. The sensor is equipped with a robust M12 plug cable exit, available in both axial and right-angle shapes, ensuring versatile installation options.
Engineered with a high degree of protection, the MV6/C0-0A boasts an IP67 rating, providing complete protection against dust and water ingress, as well as electrical damage. The sensor operates efficiently within a wide voltage range of 20 to 253VAC at 50-60Hz, and it is capable of handling load currents from 5 to 300mARMS. With a low leakage current of 6A and a minimal output voltage drop of ?3V at full load, this sensor ensures reliable performance in demanding environments.
The MV6/C0-0A is equipped with LED indicators for easy status monitoring and features a fast response time of 20ms, with a switching frequency of 25Hz. Its durable construction includes a PBT/PC housing and a PMMA active head, designed to withstand operating temperatures from -25°C to +70°C without freezing. The sensor's compact dimensions (M18x1/L=78.9mm) and lightweight design (100g) make it easy to integrate into existing systems.
This sensor is CE and cURus approved, ensuring compliance with international safety standards. It also meets EMC compatibility requirements as per EN 60947-5-2, and is tested for shocks and vibrations according to IEC standards. Supplied with M18 x 1 nuts for secure mounting, the Datasensing MV6/C0-0A Sensors are a reliable choice for applications requiring precise and consistent photoelectric sensing.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- TRIAC NC
- Output Function:
- NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
