Datasensing MVR/A0-0E Sensors
Datasensing
$109.76
The Datasensing MVR/A0-0E Sensors are advanced photoelectric sensors designed for reliable and efficient performance. These sensors feature a through-beam model with a high sensing range of 16 meters, making them ideal for various industrial applications. The M18 receiver is equipped with a plastic M12 connector, ensuring easy installation and connectivity. With a robust IP67 protection degree, these sensors offer complete protection against electrical damage and are suitable for harsh environments.
The MVR/A0-0E sensors boast a low leakage current and high output current, with a TRIAC NO output type for seamless integration into existing systems. The sensors operate within a wide voltage range of 20 to 253VAC, accommodating diverse power requirements. The axial optic position and red LED indicators provide clear status output, enhancing operational efficiency.
Engineered with precision, these sensors maintain a repeat accuracy of 5% and a thermal drift of Sr ?10%Sr, ensuring consistent performance. The compact design, with dimensions of M18x1/L=78.9mm and a weight of 30g, allows for easy integration into tight spaces. Constructed with durable PBT/PC housing and PMMA active head material, the sensors are built to withstand shocks and vibrations, adhering to IEC standards.
The MVR/A0-0E sensors are CE cURus approved and EMC compatible, meeting EN 60947-5-2 standards. They are designed to operate efficiently in temperatures ranging from -25°C to +70°C, without freezing. Supplied with M18 x 1 nuts, these sensors are ready for immediate deployment in your industrial setup.
- Nominal sensing distance:
- 16m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- TRIAC NO
- Output Function:
- NO
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 60° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
