Datasensing MVR/C0-0E Sensors
Datasensing
$109.76
The Datasensing MVR/C0-0E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a robust M18 receiver with a nominal sensing distance of 16 meters, these sensors are equipped with a plastic M12 connector for easy installation. The sensors operate on a wide voltage range of 20 to 253VAC and are capable of handling load currents from 5 to 300mARMS, with a low leakage current of 6A. They boast a high switching frequency of 25Hz and a quick response time of 20ms, ensuring efficient performance in various applications.
The MVR/C0-0E Sensors offer a wide range of models, including diffuse, retro-reflective, polarized, and through-beam options, with through-beam models providing an extended sensing range. Retro-reflective models utilize polarized light with a visible beam for enhanced accuracy. The sensors are designed with an IP67 protection degree, offering complete protection against electrical damage and ensuring durability in harsh environments.
With a compact design measuring M18x1/L=78.9mm and weighing just 30g, these sensors are constructed from durable PBT/PC materials, with an active head made of PMMA. They are approved by CE cURus and comply with EMC compatibility standards EN 60947-5-2. The sensors are resistant to shocks and vibrations, adhering to Vibration IEC 60068-2-6 and Shock IEC 60068-2-27 standards. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing MVR/C0-0E Sensors are ideal for a variety of industrial applications, providing reliable performance and easy integration.
- Nominal sensing distance:
- 16m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- TRIAC NC
- Output Function:
- NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 60° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
