Datasensing PS2/AN-0E Sensors

The Datasensing PS2/AN-0E Sensors are compact and versatile photoelectric sensors designed for a wide range of applications. With a nominal sensing distance of 100mm, these sensors utilize diffuse reflection for short-distance detection up to 200mm. The PS2/AN-0E model features a high sensing distance and sensitivity adjustment via a trimmer, ensuring precise and reliable performance. Equipped with an NPN NO output type, these sensors operate at a switching frequency of 100Hz and have a rapid response time of just 5ms. They are designed to function within an operating voltage range of 10 to 30VDC, with a no-load supply current of ? 30mA and a load current capacity of ?100mA. The sensors are protected against electrical damage with short-circuit and reverse polarity protection, and they feature a low output voltage drop of ?1.2V at a load current of 100mA. The PS2/AN-0E sensors are housed in a durable ABS material with an active head made of PMMA, offering robust performance in temperatures ranging from -25°C to +70°C. The cubic design measures 15x49x26mm and weighs 90g, making it ideal for installations with limited space. The sensors are equipped with an M12 plug for easy connections and include a red LED indicator for output state monitoring. With IP65 protection, these sensors are resistant to dust and water ingress, ensuring reliable operation in challenging environments. They are also compliant with CE and EMC standards, including EN 60947-5-2, and are designed to withstand shocks and vibrations as per IEC standards. Each sensor comes with a ST07 mounting bracket and screws for convenient installation.
