Datasensing QXP/A0-2A Sensors
Datasensing
$201.18
The Datasensing QXP/A0-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3 meters with a repeat accuracy of ? 5%. The axial and right-angle optics, combined with a visible red light, ensure long-distance capability and a precision beam. With a fast response time of 0.75-0.5 ms and a switching frequency of 750Hz, these sensors are ideal for high-speed applications.
The QXP/A0-2A sensors come equipped with two LED indicators: a red LED for output status and a green LED for stability, providing clear visual feedback. The sensors offer NPN/PNP selectable output with a high output current of over 300 mA, ensuring compatibility with various systems. The sensitivity can be adjusted using a trimmer, allowing for fine-tuning to suit specific application needs.
Built to withstand harsh environments, these sensors operate within a temperature range of -25°C to +70°C and are protected against short circuits and reverse polarity. The robust ABS housing and IP65 mechanical protection ensure durability and resistance to shocks and vibrations, complying with IEC standards.
The sensors are supplied with ST70 mounting brackets and screws for easy installation. With a compact cubic design measuring 15x23x40 mm and a weight of 70g, the QXP/A0-2A sensors are a versatile and reliable choice for industrial automation and control applications.
- Nominal sensing distance:
- 3m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x67
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
