Datasensing RX6/0T-1B Sensors
Datasensing
$149.03
The Datasensing RX6/0T-1B Sensors are designed for high-performance photoelectric sensing with a diffuse reflection model, offering a nominal sensing distance of 1 meter. These sensors are equipped with a multifunctional DECOUT® relay output, allowing for NPN/PNP and NO/NC selectable configurations. The sensors feature a timer function with delay on, delay off, and one-shot capabilities, along with a trimmer for precise sensitivity adjustment.
With a compact cubic design measuring 26x86.6x61 mm and weighing just 90g, these sensors are easy to install using the included ST81 mounting bracket and screws. The sensors are built to withstand harsh environments, with an IP65 degree of protection and an operating temperature range of -25°C to +70°C.
The RX6/0T-1B Sensors are equipped with LED indicators for 360° visibility, providing clear status updates with red and green lights for output status and stability. The sensors are designed with an M12 standard plug for easy connectivity and offer short-circuit and reverse polarity protection for reliable operation.
Ideal for applications requiring high sensing distance and fine detection, these sensors are compatible with a wide range of installations, thanks to their high performance and versatile design. The sensors are CE and cULus approved, ensuring compliance with international standards for safety and performance.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm EG=1,5
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable Decout NO/NC Selectable
- Output Function:
- Decout NO/NC Selectable
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 5000lux (incandescent lamp)
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
