The Datasensing SA6/0P-1C Sensors are advanced photoelectric sensors designed for precise and reliable detection. With a nominal sensing distance of 400mm, these sensors utilize diffuse reflection technology, making them ideal for medium-distance applications up to 600mm. The sensors feature a sensitivity adjustment trimmer, allowing for fine-tuning to suit specific needs. Equipped with a double LED indicator for power and status output, they offer clear visual feedback. The sensors provide a selectable NO/NC output and are protected against electrical damage with IP65 and IP67 protection ratings, ensuring durability in various environments.
These sensors operate on a voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA and a load current capacity of ?100mA. They are designed to handle a maximum ripple content of ?10% and feature short-circuit and reverse polarity protection for enhanced safety. The LED infrared emission at 880nm ensures reliable performance even in challenging lighting conditions, with resistance to external light interference up to 10,000 lux.
Constructed with a robust nickel-plated brass housing and a nylon cable exit, the sensors are built to withstand harsh conditions, with an operating temperature range of -25°C to +70°C. The compact dimensions of 21.4mm x 90mm and a weight of 140g make them easy to integrate into various systems. Supplied with M18 x 1 nuts, these sensors are ready for installation and are CE approved, meeting EMC compatibility standards EN 60947-5-2.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green (powerON), Yellow (Status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 140g
- Housing Material:
- Nickel-plated brass / Nylon cable exit
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
