Datasensing SA6/0P-1C86 Sensors
Datasensing
$154.77
The Datasensing SA6/0P-1C86 Sensors are advanced photoelectric sensors designed for precise detection with a nominal sensing distance of 400mm. Utilizing a diffuse reflection principle, these sensors are ideal for medium-distance applications up to 600mm. They feature a PNP output type with L/D selectable functionality, ensuring versatile integration into various systems. The sensors are equipped with a 5m PVC cable and a 90° connection for flexible installation.
Engineered with a robust nickel-plated brass housing and a PMMA active head, these sensors offer durability and reliability in challenging environments. They are protected against short circuits and reverse polarity, with an IP67 mechanical protection rating, making them suitable for industrial applications. The sensors operate efficiently within a voltage range of 10
30VDC, with a low no-load supply current of ?30mA and a load current of ?100mA.
With a high switching frequency of 1kHz and a rapid response time of 500µs, the SA6/0P-1C86 Sensors ensure quick and accurate detection. The sensitivity can be adjusted via a trimmer, and the sensors are equipped with LED indicators for power and status output. They are designed to withstand shocks and vibrations as per IEC standards and are CE approved for quality assurance. The sensors come with M18 x 1 nuts for easy mounting and are compatible with a wide range of operating temperatures from -25°C to +70°C.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green (powerON), Yellow (Status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Housing Material:
- Nickel-plated brass / Nylon cable exit
- Connections:
- 5m PVC cable 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- Nuts M18 x 1
- Dimensions:
- 21,4mmx90mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
