The Datasensing SH4/E-0EIA Sensors are advanced safety sensors designed for high-performance applications. Featuring a Type 4 PLe emitter, these sensors are equipped with an M18 plastic housing and an axial M12 connection, ensuring robust and reliable operation. With a nominal sensing distance of 10 meters and a thermal drift of Sr ? 10%, they offer precise single-beam resolution and controlled height. The sensors operate at a frequency of 123 kHz and are compliant with EN50100 Category 2 and Category 4 standards, making them ideal for integration into safety systems that meet EN ISO 13849 requirements.
These sensors are designed to work seamlessly with the SBCR03 control unit, providing a comprehensive safety solution. The M18 models offer an operating distance of 10 meters for axial optics and 5 meters for radial optics, while the M30 models extend this range to 60 meters. The sensors feature LED indicators for easy status monitoring, with a yellow LED indicating power and a red LED for emission. They are built to withstand harsh environments, with an IP67 degree of protection, and are approved by CE and TÜV.
Constructed with a durable PBT housing and a glass active head, the sensors can operate in temperatures ranging from -20°C to +55°C and can be stored in temperatures as low as -40°C. They are resistant to shocks and vibrations, adhering to IEC60068-2-29 and IEC60068-2-6 standards. The sensors are powered by an operating voltage of 10 to 30 Vdc, with a no-load supply current of ? 25mA and a maximum ripple content of ? 5 Vpp. Supplied with two nuts for easy installation, these sensors are a reliable choice for ensuring safety in industrial environments.
- Nominal sensing distance:
- 10m (ExG=4)
- Thermal drift of Sr:
- ? 10%
- Resolution:
- Single-beam
- controlled height:
- Single-beam
- Effective Aperture Angle:
- ? ±2,5°
- Effective Aperture Angle:
- Typical ±1,8°
- Function Principle:
- Emitter
- Control unit to be used:
- SBCR03
- Description:
- M18 Type 4 Safety Photocell Emitter
- Type:
- Type 4 safety photocell
- SIL:
- 3
- SILCL:
- 3
- PL:
- e
- PFHd:
- 8,10E-10
- MTTFd:
- 20 years
- Operating Voltage:
- 10 30 Vdc
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ? 5 Vpp
- LED indicators:
- Yellow (power)
- Emission:
- Red
- Test levels:
- <5V emission active >15V emission inactive
- Housing Material:
- PBT
- Connections:
- M12 plug
- Active Head Material:
- Glass
- Operating temperature:
- -20°C +55°C
- Storage temperature:
- -40°C +75°C
- Approvals:
- CE, TÜV
- Shocks and vibrations:
- 10g - 16ms (according to IEC600068-2-29) 10Hz 55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Operating Temperature:
- -20 +55°C (Without freeze)
- Mechanical Protection:
- IP67
