Datasensing SH4/R-0KIA Sensors
Datasensing
$205.94
The Datasensing SH4/R-0KIA Sensors are advanced safety sensor receivers designed for high-performance industrial applications. These Type 4 PLe safety photocell receivers feature a robust M18 plastic housing with a 90° M12 connection, ensuring reliable operation in demanding environments. With a nominal sensing distance of 10 meters and a thermal drift of Sr ? 10%, these sensors provide precise and consistent performance.
Equipped with LED indicators for easy alignment, the SH4/R-0KIA sensors are compliant with EN50100 Category 2 and Category 4 standards, making them suitable for integration into safety systems that meet EN ISO 13849 requirements. The sensors operate at a frequency of 123 kHz and are designed to be used in conjunction with the SBCR03 control unit, offering a seamless connection with any safety module.
The sensors boast a single-beam resolution and an effective aperture angle of ? ±2.5°, with a typical angle of ±1.8°. They feature a totem-pole output type, with a response time of 200µs for light/dark transitions and 400µs for dark/light transitions. Operating within a voltage range of 10 to 30 Vdc, these sensors have a no-load supply current of ? 25mA and a load current of ? 70mA, ensuring energy-efficient performance.
Built to withstand harsh conditions, the SH4/R-0KIA sensors have an IP67 degree of protection, are CE and TÜV approved, and can operate in temperatures ranging from -20°C to +55°C. They are also resistant to shocks and vibrations, adhering to IEC600068-2-29 and 60068-2-6 standards. Supplied with two nuts for easy installation, these sensors are an ideal choice for enhancing safety in industrial settings.
- Nominal sensing distance:
- 10m (ExG=4)
- Thermal drift of Sr:
- ? 10%
- Resolution:
- Single-beam
- controlled height:
- Single-beam
- Effective Aperture Angle:
- ? ±2,5°
- Effective Aperture Angle:
- Typical ±1,8°
- Function Principle:
- Receiver
- Control unit to be used:
- SBCR03
- Description:
- M18 Type 4 Safety Photocell Receiver
- Type:
- Type 4 safety photocell
- SIL:
- 3
- SILCL:
- 3
- PL:
- e
- PFHd:
- 8,10E-10
- MTTFd:
- 20 years
- Output type:
- Totem-pole
- Output Function:
- To be connectred to SBCR03
- Resposnse time for light/dark transition:
- 200µs
- Resposnse time for dark/light transition:
- 400µs
- Operating Voltage:
- 10 30 Vdc
- No-Load supply current:
- ? 25mA
- Load current:
- ? 70mA
- Output voltage drop:
- 2,5V @ 50mA
- Max ripple content:
- ? 5 Vpp
- LED indicators:
- Yellow (alignement)
- Housing Material:
- PBT
- Connections:
- M12 plug
- Active Head Material:
- Glass
- Operating temperature:
- -20°C +55°C
- Storage temperature:
- -40°C +75°C
- Approvals:
- CE, TÜV
- Shocks and vibrations:
- 10g - 16ms (according to IEC600068-2-29) 10Hz 55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Operating Temperature:
- -20 +55°C (Without freeze)
- Mechanical Protection:
- IP67
