Datasensing SH4/R-2EIC Sensors
Datasensing
$150.85
The Datasensing SH4/R-2EIC Sensors are advanced safety sensor receivers designed for high-performance industrial applications. These Type 4 safety photocell receivers feature a robust M18 plastic housing with a 90° M12 connector, ensuring reliable operation in demanding environments. With a nominal sensing distance of 5 meters and a thermal drift of Sr ? 10%, these sensors provide precise single-beam resolution and controlled height detection.
Equipped with LED indicators for easy alignment, the SH4/R-2EIC Sensors are compliant with EN50100 Category 2 and Category 4 standards, making them suitable for integration into safety systems that meet EN ISO 13849 requirements. The sensors operate at a frequency of 123 kHz and are designed to work with external safety control units that have an automatic optics test function, excluding the SBCR03 control unit.
These sensors offer a totem-pole output type with a response time of 200µs for light/dark transitions and 400µs for dark/light transitions. They operate within a voltage range of 10 to 30 Vdc, with a no-load supply current of ? 25mA and a load current of ? 70mA. The output voltage drop is 2.5V at 50mA, and the sensors can handle a maximum ripple content of ? 5 Vpp.
Built to withstand harsh conditions, the SH4/R-2EIC Sensors have an IP67 degree of protection, are CE and TÜV approved, and can operate in temperatures ranging from -20°C to +55°C. They are also resistant to shocks and vibrations as per IEC600068-2-29 and 60068-2-6 standards. Supplied with two nuts for easy installation, these sensors are an ideal choice for ensuring safety and efficiency in industrial settings.
- Nominal sensing distance:
- 5m (ExG=2)
- Thermal drift of Sr:
- ? 10%
- Resolution:
- Single-beam
- controlled height:
- Single-beam
- Effective Aperture Angle:
- ? ±2,5°
- Effective Aperture Angle:
- Typical ±1,8°
- Function Principle:
- Receiver
- Notes:
- not working with SBCR03 control unit. To be used with external safety control unit with automatic optics test function
- Description:
- M18 Type 4 Safety Photocell Receiver
- Type:
- Type 4 safety photocell
- SIL:
- 3
- SILCL:
- 3
- PL:
- e
- PFHd:
- 8,10E-10
- MTTFd:
- 20 years
- Output type:
- Totem-pole
- Resposnse time for light/dark transition:
- 200µs
- Resposnse time for dark/light transition:
- 400µs
- Operating Voltage:
- 10 30 Vdc
- No-Load supply current:
- ? 25mA
- Load current:
- ? 70mA
- Output voltage drop:
- 2,5V @ 50mA
- Max ripple content:
- ? 5 Vpp
- LED indicators:
- Yellow (alignement)
- Housing Material:
- PBT
- Connections:
- M12 plug
- Active Head Material:
- Glass
- Operating temperature:
- -20°C +55°C
- Storage temperature:
- -40°C +75°C
- Approvals:
- CE, TÜV
- Shocks and vibrations:
- 10g - 16ms (according to IEC600068-2-29) 10Hz 55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Operating Temperature:
- -20 +55°C (Without freeze)
- Mechanical Protection:
- IP67
