Datasensing SP3/0P-0E Sensors
Datasensing
$109.03
The Datasensing SP3/0P-0E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection function with a nominal sensing distance of 100mm, these sensors are ideal for short-distance applications. The models come with side sensitivity adjustment on both axial and right-angle optics, allowing for flexible installation and operation. The sensors offer LO/DO selectable output and are equipped with a PNP L/D selectable output type, ensuring compatibility with various systems.
Built to withstand harsh environments, the SP3/0P-0E Sensors boast an IP67 protection degree, providing complete protection against electrical damages and ensuring durability in challenging conditions. The sensors are also ATEX models, category 3, available upon request, making them suitable for use in potentially explosive atmospheres.
The sensors feature a yellow LED status indicator for easy monitoring and are equipped with comprehensive protection features, including short-circuit protection, reverse polarity protection, and impulsive overvoltage protection. With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors deliver fast and accurate performance.
Constructed with robust materials, the housing is made of PBT/PC plug, and the active head is crafted from PMMA, ensuring longevity and reliability. The sensors operate efficiently within a temperature range of -25°C to +70°C, without freezing, and are resistant to shocks and vibrations as per IEC standards.
The SP3/0P-0E Sensors are CE and cULus listed, ensuring compliance with international safety standards. They come with supplied accessories, including M18 x 1 nuts and a screwdriver, for easy installation. With a compact design and a weight of just 30g, these sensors are a versatile and dependable choice for a wide range of industrial applications.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Radial 90°
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
