Datasensing SPG/AP-0E Sensors
Datasensing
$102.84
The Datasensing SPG/AP-0E Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 8 meters, these sensors are equipped with a PNP NO output type and feature a radial 90° optic position for versatile application. The robust design includes a plastic M12 connector and a durable PBT/PC housing, ensuring complete protection against electrical damages and environmental factors, with an IP67 protection degree.
These sensors are engineered for efficiency, offering a switching frequency of 250Hz and a rapid response time of 2ms. They operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 20mA and a load current of ?100mA. The sensors are equipped with LED indicators for easy status monitoring and provide short-circuit and reverse polarity protection for enhanced safety.
The SPG/AP-0E models are designed to withstand harsh conditions, with an operating temperature range of -25°C to +70°C and resistance to shocks and vibrations as per IEC standards. They are also compatible with ATEX models, category 3, available upon request, and are approved by CE and cULus standards, ensuring compliance and reliability in various industrial applications.
Supplied with M18 x 1 nuts and a screwdriver, these sensors are easy to install and maintain, making them an ideal choice for applications requiring precise object detection and reliable performance.
- Nominal sensing distance:
- 8m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- minimum detectable object:
- Ø 4mm
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Radial 90°
- Output type:
- PNP NO
- Output Function:
- NO
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
