Datasensing SPP/0P-1E6X Sensors
Datasensing
$146.15
The Datasensing SPP/0P-1E6X Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 4 meters and are equipped with a PNP L/D selectable output type. The robust construction includes a nickel-plated brass housing with a PMMA active head, ensuring durability and resistance to harsh environments. With a radial 90° optic position and enhanced emission capabilities, these sensors are optimized for use with the RL110 reflector. They operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 30mA and a load current capacity of ?100mA. The sensors are equipped with LED indicators for status output and provide short-circuit and reverse polarity protection. Designed to withstand shocks and vibrations, they comply with EMC compatibility standards EN 60947-5-2 and are approved by CE and cULus. The M12 plug connection and supplied M18 x 1 nuts facilitate easy installation, while the IP67 mechanical protection rating ensures reliable performance in challenging conditions. Ideal for applications requiring high repeat accuracy and minimal thermal drift, the SPP/0P-1E6X Sensors are a dependable choice for industrial automation needs.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- nuts M18 x 1
- Dimensions:
- M18 x 1 /L =75,7mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
