Datasensing SS0/0N-0E Sensors
Datasensing
$107.78
The Datasensing SS0/0N-0E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a nominal sensing distance of 50mm, these sensors utilize a blackground suppression function principle, ensuring accurate detection even in challenging environments. With a robust IP67 protection degree, they are safeguarded against electrical damages and are suitable for use in harsh conditions. The sensors offer a selectable NPN L/D output type, with a switching frequency of 1kHz and a rapid response time of 500µs, making them ideal for high-speed applications.
Equipped with a yellow LED status indicator, the SS0/0N-0E Sensors provide clear operational feedback. They are designed with a durable PBT housing and a PMMA active head, ensuring longevity and resistance to environmental factors. The sensors are compatible with M12 connections and come with supplied M18 x 1 nuts for easy installation.
These sensors are CE and cULus listed, meeting stringent safety and performance standards. They offer complete protection against short-circuits, reverse polarity, and impulsive overvoltage, ensuring reliable operation. With a wide operating temperature range of -25°C to +70°C, they are versatile for various industrial applications. The Datasensing SS0/0N-0E Sensors are an excellent choice for those seeking high-performance sensing solutions with comprehensive protection features.
- Nominal sensing distance:
- 50mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- minimum detectable object:
- 1mm
- Sensitivity adjustment:
- No
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
