Datasensing SS2/LN-1E Sensors

The Datasensing SS2/LN-1E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection principle with a nominal sensing distance of 100mm, these sensors are ideal for short-distance applications. The robust design includes a nickel-plated brass housing with an IP67 protection rating, ensuring durability and resistance to harsh environments. The sensors are equipped with an NPN Lon output type and offer a switching frequency of 250Hz, with a rapid response time of 2ms. The SS2/LN-1E models come with side sensitivity adjustment on both axial and right-angle optics, providing flexibility in installation and operation. They are equipped with a yellow LED status indicator for easy monitoring and are protected against electrical damages, including short-circuit and reverse polarity protection. The sensors operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA and a load current capacity of ?100mA. These sensors are designed to withstand extreme temperatures, operating between -25°C and +70°C without freezing. They are also resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from sunlight. The SS2/LN-1E sensors are CE and cULus approved, ensuring compliance with international safety standards. Optional ATEX models, category 3, are available upon request for use in potentially explosive atmospheres. With complete protection against impulsive overvoltage and a high degree of mechanical protection, the Datasensing SS2/LN-1E Sensors are a reliable choice for industrial applications requiring precise and consistent performance.
