Datasensing SS7/0N-0E Sensors
Datasensing
$92.63
The Datasensing SS7/0N-0E Sensors are advanced photoelectric sensors designed for precise and reliable detection. With a nominal sensing distance of 400mm, these sensors utilize diffuse reflection technology, making them ideal for medium-distance applications up to 600mm. The sensors feature a trimmer for sensitivity adjustment, ensuring optimal performance in various environments.
Equipped with an NPN L/D selectable output, the SS7/0N-0E Sensors offer flexibility in output function, with a switching frequency of 250Hz and a rapid response time of 2ms. They operate efficiently within a voltage range of 10 to 30VDC, with minimal power consumption and a low output voltage drop.
Built to withstand challenging conditions, these sensors boast an IP67 protection degree, providing complete protection against electrical damages and environmental factors. The robust housing, made from PBT and PC materials, ensures durability, while the PMMA active head material enhances performance.
The sensors are equipped with LED indicators for easy status monitoring and offer comprehensive protection features, including short-circuit and reverse polarity protection, as well as impulsive overvoltage protection. They are designed to resist interference from external light sources, withstanding up to 3000lux from incandescent lamps and 10000lux from sunlight.
With approvals from CE and cULus, and compliance with EMC compatibility standards, the Datasensing SS7/0N-0E Sensors are a reliable choice for industrial applications. Supplied with M18 x 1 nuts and a screwdriver, these sensors are easy to install and maintain, making them a versatile and efficient solution for your sensing needs.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
