Datasensing SSC/0N-0A Sensors

The Datasensing SSC/0N-0A Sensors are designed for precision and reliability in various industrial applications. Featuring a retroreflective function principle, these sensors offer a nominal sensing distance of 5 meters with a thermal drift of Sr at ?10% Sr and a repeat accuracy of 5%. The optic position is axial, and the output type is NPN L/D selectable, providing flexibility in output function. With a switching frequency of 250Hz and a response time of just 2ms, these sensors ensure quick and accurate detection. Built to withstand harsh environments, the SSC/0N-0A Sensors come with an IP67 protection degree, safeguarding against dust and water ingress. They are equipped with LED status indicators for easy monitoring and offer complete protection against electrical damages, including short-circuit and reverse polarity protection. The sensors operate within a voltage range of 10…30VDC, with a no-load supply current of ? 30mA and a load current of ?100mA. Constructed with durable materials, the housing is made of PBT/PC with a PMMA active head, and the sensors are designed to endure operating temperatures from -25°C to +70°C. The compact dimensions of M18 x 1/L=63.9mm and a weight of 70g make them easy to install, with a 2m PVC cable for connections. The sensors are CE and cULus listed, ensuring compliance with international standards, and are compatible with ATEX models, cat. 3, available upon request. Ideal for environments with high interference from external light, they can handle up to 3000lux from incandescent lamps and 10000lux from sunlight.
