Datasensing SSC/0P-0A Sensors
Datasensing
$83.80
The Datasensing SSC/0P-0A Sensors are high-performance photoelectric sensors designed for reliable retroreflective detection up to 4 meters. Featuring a PNP L/D selectable output, these sensors offer flexibility with LO/DO selectable output and models with side sensing adjustment on axial and right-angle optics. Built to withstand harsh environments, they boast an IP67 protection degree, ensuring complete protection against electrical damages. The sensors are equipped with a yellow LED status indicator for easy monitoring and are CE and cULus listed for quality assurance.
With a nominal sensing distance of 5 meters and a thermal drift of Sr ?10% Sr, these sensors provide consistent performance with a repeat accuracy of 5%. They operate efficiently with a switching frequency of 250Hz and a response time of just 2ms. The sensors are powered by an operating voltage of 10
30VDC, with a no-load supply current of ? 30mA and a load current of ?100mA. Designed for durability, they feature a robust PBT/PC housing and a PMMA active head material, withstanding operating temperatures from -25°C to +70°C.
The SSC/0P-0A Sensors are equipped with short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, ensuring reliable operation in various conditions. They are resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from sunlight. The sensors come with a 2m PVC cable for easy installation and are supplied with M18 x 1 nuts for secure mounting. Ideal for industrial applications, these sensors offer dependable performance and robust protection in demanding environments.
- Nominal sensing distance:
- 5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflective
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
