Datasensing SSC/DN-0E Sensors
Datasensing
$83.80
The Datasensing SSC/DN-0E Sensors are high-performance photoelectric sensors designed for reliable retroreflective sensing up to 4 meters. Featuring a robust NPN Don plastic connector with an M12 plug, these sensors offer side sensitivity adjustment on both axial and right-angle optics. With LO/DO selectable output and optional ATEX models for category 3 environments, they are versatile for various applications. The sensors are equipped with a yellow LED status indicator and provide complete protection against electrical damages, including short-circuit and reverse polarity protection. They are built to withstand harsh conditions with an IP67 protection degree and are CE and cULus listed for quality assurance.
Key specifications include a nominal sensing distance of 5 meters, a thermal drift of ?10% Sr, and a repeat accuracy of 5%. The sensors operate on a voltage range of 10 to 30VDC, with a no-load supply current of ?30mA and a load current of ?100mA. They feature a fast switching frequency of 250Hz and a response time of 2ms, ensuring quick and accurate detection. The housing is made from durable PBT with a PMMA active head, and the sensors are designed to operate in temperatures ranging from -25°C to +70°C. With a compact M18 x 1 design and a weight of just 30g, these sensors are easy to install and integrate into existing systems.
- Nominal sensing distance:
- 5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflective
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- NPN Don
- Output Function:
- Don
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
