Datasensing SSD/0N-0A Sensors
Datasensing
$82.59
The Datasensing SSD/0N-0A Sensors are high-performance photoelectric sensors designed for precise detection tasks. Featuring a robust M18 receiver with a nominal sensing distance of 14 meters, these sensors offer adjustable sensitivity via a trimmer for optimal performance. The NPN L/D selectable output ensures versatile application compatibility, while the axial optic position enhances detection accuracy. Built to withstand harsh environments, the sensors boast an IP67 protection rating, safeguarding against electrical damages and ensuring reliable operation in temperatures ranging from -25°C to +70°C. The LED infrared emission at 880nm provides consistent performance, even in challenging lighting conditions, with interference resistance up to 10,000 lux. Additional features include short-circuit and reverse polarity protection, a fast response time of 2ms, and a switching frequency of 250Hz. The sensors come with a 2-meter PVC cable for easy installation and are approved by CE and cULus standards, making them a reliable choice for industrial applications. Supplied with M18 x 1 nuts and a screwdriver, these sensors are ready for immediate deployment.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Check Input:
- BK/2 connected to 0Vdc swithing off the emission
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
