Datasensing SSF/0P-1A Sensors
Datasensing
$127.58
The Datasensing SSF/0P-1A Sensors are advanced optical fibre amplifiers designed for precision and reliability. Featuring a robust M18 housing, these sensors operate on a 10...30VDC power supply and offer a PNP L/D selectable output. With a teach-in button for easy sensitivity adjustment, they ensure optimal performance across various applications. The sensors boast a high switching frequency of 800Hz and a rapid response time of 625µs, making them ideal for fast-paced environments.
Equipped with a yellow LED status indicator, they provide clear output status visibility. The sensors are built to withstand challenging conditions, offering complete protection against electrical damages, including short-circuit and reverse polarity protection. They are also designed to resist interference from external light sources, withstanding up to 3,000 lux from incandescent lamps and 10,000 lux from sunlight.
Constructed with a durable nickel brass housing and a 2m PVC cable, these sensors are IP67 rated for mechanical protection, ensuring reliable operation in harsh environments. They are CE and cULus approved, meeting stringent safety and performance standards. With a compact design and a weight of 130g, they are easy to install and integrate into existing systems. The Datasensing SSF/0P-1A Sensors are the perfect choice for applications requiring precise optical sensing with robust protection and adaptability.
- Nominal sensing distance:
- Depending on optical fibres used
- Thermal drift of Sr:
- 10 % Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Optic fiber amplifier
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 800Hz
- Response time:
- 625µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?100mA
- Leakage current:
- ? 10 µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (output status)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 130 g
- Housing Material:
- Nickel brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- Depending on optical fibres
- Tightening torque:
- 25Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Mechanical Protection:
- IP67
