Datasensing SSH/00-0E Sensors

The Datasensing SSH/00-0E Sensors are designed for precision and reliability in industrial applications. Featuring a nominal sensing distance of 14 meters, these sensors are equipped with a side sensitivity adjustment on both axial and right-angle optics, allowing for versatile installation options. The LO/DO selectable output and LED status indicator ensure easy monitoring and operation. Built to withstand harsh environments, the sensors offer complete protection against electrical damages and are rated with an IP67 protection degree, making them suitable for use in demanding conditions. These sensors are available with ATEX models, category 3, upon request, and are approved by CE and cULus standards, ensuring compliance with international safety regulations. The emitter operates on a 10 to 30VDC voltage range, with a no-load supply current of ? 40mA and a maximum ripple content of ?10%. The LED infrared emission at 880nm provides reliable performance, while the reverse polarity and impulsive overvoltage protection enhance durability. Constructed with a robust PBT housing and a PMMA active head, the sensors are designed to endure temperatures ranging from -25°C to +70°C without freezing. The M18 x 1 dimensions and M12 plug connections facilitate easy integration into existing systems. With a weight of just 30g and a tightening torque of 1Nm, these sensors are both lightweight and secure. Supplied with M18 x 1 nuts, the Datasensing SSH/00-0E Sensors are the ideal choice for those seeking high-performance sensing solutions with exceptional mechanical protection and EMC compatibility.
