Datasensing SSH/X0-0A Sensors
Datasensing
$64.84
The Datasensing SSH/X0-0A Sensors are high-performance photoelectric sensors designed for precise and reliable detection. With a nominal sensing distance of 14 meters, these sensors feature an emitter function principle and an axial optic position, ensuring accurate performance in various applications. The sensors are equipped with a yellow LED indicator for power status and offer complete protection against electrical damages, including reverse polarity and impulsive overvoltage protection.
Constructed with durable PBT/PC housing and a PMMA active head, the sensors are built to withstand harsh environments, boasting an IP67 protection degree. They operate efficiently within a temperature range of -25°C to +70°C, without freezing, and are resistant to shocks and vibrations as per IEC standards. The sensors come with a 2-meter PVC cable for easy installation and are CE and cULus approved, ensuring compliance with international safety standards.
For added versatility, models with side sensor adjustment on axial and right-angle optics are available, along with LO/DO selectable output options. ATEX models, category 3, can be requested for specialized applications. The compact design, with dimensions of M18 x 1/L=63.9mm and a weight of 70g, makes these sensors an ideal choice for a wide range of industrial and commercial uses.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Check Input:
- BK/2 connected to 0Vdc swithing off the emission
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 40mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow(powerON)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
