Datasensing SSH/X0-0E Sensors

The Datasensing SSH/X0-0E Sensors are advanced photoelectric sensors designed for precise and reliable performance. Featuring a nominal sensing distance of 14 meters, these sensors are equipped with a side sensing adjustment on both axial and right-angle optics, allowing for versatile application. The LO/DO selectable output and LED status indicator ensure easy monitoring and operation. Built to withstand harsh environments, the sensors offer complete protection against electrical damages and are rated with an IP67 protection degree. They are also available in ATEX models, category 3, upon request, and are CE and cULus listed for quality assurance. The sensors operate on a voltage range of 10 to 30VDC, with a no-load supply current of ? 40mA and a maximum ripple content of ?10%. They feature reverse polarity and impulsive overvoltage protection, ensuring durability and longevity. The emission is powered by an LED Infrared at 880nm, with a time delay before availability of ?200ms. Constructed with a robust PBT/PC plug housing and PMMA active head material, the sensors are designed to endure operating temperatures from -25°C to +70°C without freezing. The M18 x 1 dimensions and M12 plug connections make installation straightforward, and the sensors come with supplied accessories, including nuts M18 x 1. With EMC compatibility to EN 60947-5-2 and resistance to shocks and vibrations as per IEC standards, the Datasensing SSH/X0-0E Sensors are an ideal choice for industrial applications requiring high precision and reliability.
