Datasensing SSP/0N-0A Sensors
Datasensing
$90.57
The Datasensing SSP/0N-0A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 4 meters and are equipped with a robust NPN L/D selectable output. The sensors are housed in a durable PBT/PC material with a 2-meter PVC cable exit, ensuring long-lasting performance even in challenging environments. With an IP67 protection degree, they are fully protected against electrical damages and are suitable for use in a wide range of industrial applications.
These sensors are designed with user convenience in mind, featuring a side sensitivity adjustment on both axial and right-angle optics. The LED status indicator provides clear visibility of the sensor's operational status, while the short-circuit and reverse polarity protection ensure safe and reliable operation. The SSP/0N-0A models are also available in ATEX category 3 versions upon request, making them suitable for use in potentially explosive atmospheres.
With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors are ideal for applications requiring fast and accurate detection. The sensors are capable of withstanding external light interference up to 3000 lux from incandescent lamps and 10000 lux from sunlight, ensuring reliable performance in various lighting conditions. Additionally, the sensors are CE and cULus listed, meeting international standards for safety and performance.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
