Datasensing SSV/AP-0A Sensors
Datasensing
$75.48
The Datasensing SSV/AP-0A Sensors are high-performance photoelectric sensors designed for precise detection tasks. Featuring a robust M18 receiver with a nominal sensing distance of 3 meters, these sensors are equipped with a NO/PNP output type and a 2-meter PVC cable for easy installation. The sensors boast a high switching frequency of 250Hz and a rapid response time of 2ms, ensuring quick and accurate detection. With a durable PBT/PC housing and PMMA active head material, they are built to withstand harsh environments, offering IP67 protection against dust and water ingress.
These sensors are designed with user convenience in mind, featuring a yellow LED status indicator for easy monitoring. They are equipped with comprehensive protection features, including short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring reliable operation. The sensors are also resistant to external light interference, withstanding up to 5000 lux from incandescent lamps and 10000 lux from sunlight.
The SSV/AP-0A Sensors are CE and cULus approved, meeting stringent safety and performance standards. They are suitable for a wide range of applications, with an operating temperature range of -25°C to +70°C, making them ideal for use in various industrial environments. The sensors come with supplied accessories, including M18 x 1 nuts, for secure mounting. With their advanced features and robust construction, the Datasensing SSV/AP-0A Sensors are an excellent choice for reliable and efficient photoelectric sensing solutions.
- Nominal sensing distance:
- 3m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- minimum detectable object:
- Ø 1mm
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP NO
- Output Function:
- NO
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
