Datasensing SSZ/0N-0E Sensors
Datasensing
$71.49
The Datasensing SSZ/0N-0E Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 14 meters, these sensors are equipped with an NPN L/D selectable output and feature a robust plastic M12 connector. The M18 receiver model offers axial optic positioning and is built to withstand challenging environments, boasting an IP67 protection degree.
These sensors are engineered with advanced features such as a LED status indicator, complete protection against electrical damages, and are CE and cULus listed. They are capable of operating within a wide voltage range of 10 to 30VDC, with a no-load supply current of ? 30mA and a load current of ?100mA. The sensors are designed to handle a maximum ripple content of ?10% and provide short-circuit and reverse polarity protection.
The SSZ/0N-0E Sensors are constructed with durable materials, including a PBT/PC housing and a PMMA active head, ensuring longevity and resilience. They are suitable for use in temperatures ranging from -25°C to +70°C, without freezing, and can withstand shocks and vibrations as per IEC standards. Additionally, these sensors offer impulsive overvoltage protection and are resistant to interference from external light sources, making them ideal for various industrial applications. Supplied with M18 x 1 nuts, these sensors are ready for seamless integration into your system.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
